Aptiv Micro 64 Female Tin (Sn) Plated Sealed Terminal 22-20 AWG
100-00172
$0.75
Attributes
- Family: Micro
- Manufacturer: Aptiv (Delphi)
- Sealed: Sealed
- Series: 64
- Alternate MFR SKUs: 15305174-L
- Blade Width MM: 0.64
- Max Operating Temp: 125
- Max Wire Size Awg: 20
- Max Wire Size MM2: 0.5
- MFR SKU: 15305174
- Min Insulation Diameter MM: 1.2
- Min Operating Temp C: -40
- Min Wire Size Awg: 22
- Min Wire Size MM2: 0.35
- Plating: Tin (Sn)
- Gender: Female
Dimensions:
- Weight: 0.15 Grams
This terminal is used with the Gen III LS type truck injector.
